Danfoss Type SG SGN SGI Sight Glass 1/4'' 3/8'' 1/2'' 5/8'' 7/8'' ODF x ODF

Productdetails:

Plaats van herkomst:	China
Merknaam:	BRANDO
Certificering:	None
Modelnummer:	SGN, SGI

Betalen & Verzenden Algemene voorwaarden:

Min. bestelaantal:	5 stuks
Prijs:	Onderhandelbaar
Verpakking Details:	Binnendoos, karton, pallet
Levertijd:	Onderhandeling
Betalingscondities:	T/T,Western Union,MoneyGram
Levering vermogen:	100.000 stuks per maand

Contact

Gedetailleerde productomschrijving

Productnaam:	Verkoelingsscherm	Poortgrootte:	1/4'', 3/8'', 1/2'', 5/8'', 7/8'
Verbinding:	Soldeer (ODF X ODF)	Mediatemperatuurbereik:	-58 tot 175 °F
Maximale werkdruk:	500 psig	Koelmiddel:	CFC's, HCFC's, HFC's
Markeren:	Sight Glass ODF , low pressure sight glass , DANFOSS SGN 5/8''

Danfoss Type SG SGN SGI Sight Glass 1/4'' 3/8'' 1/2'' 5/8'' 7/8'' ODF x ODF

SG is sight glasses for low pressure application (Max Working Pressure 500 psig). SG is available with flare, solder and socket connections, and with and without moisture indicators. SG and SGR, without moisture indicator, are mainly used to indicate the condition of the refrigerant in the liquid line or the flow in the oil return line from the oil separator. SGI / SGN and SGRI / SGRN are equipped with sensitive indicators that reflects a color, which depends on the moisture content in the refrigerant.

Main Dimension of SG series Refrigeration Sight Glass:

Model	Connection Type	Connection Size	L	L1	H	H1	B1	φD
Model	Connection Type	inch
SGI / SGN 6	Flare ext x ext	1/4''	2.638	-	0.945	0.551	0.551	1.063
SGI / SGN 10	Flare ext x ext	3/8''	3.228	-	1.102	0.63	0.748	1.26
SGI / SGN 6	Flare int x ext	1/4''	1.811	-	0.945	0.551	0.63	1.063
SGI / SGN 10		3/8''	2.244	-	1.181	0.669	0.866	1.26
SGI / SGN 12		1/2''	2.323	-	1.181	1.181	0.945	1.26
SGI / SGN 6s	ODF x ODF Solder	1/4''	3.976	0.276	0.945	0.551	0.551	1.063
SGI / SGN 10s		3/8''	4.685	0.354	0.945	0.551	0.551	1.063
SGI / SGN 12s		1/2''	5.748	0.394	1.102	0.63	0.748	1.063
SGI / SGN 16s		5/8''	5.748	0.472	1.181	0.709	0.866	1.063
SGI / SGN 22s		7/8''	6.811	0.699	1.457	0.827	1.063	1.26
SGI / SGN 6s	ODF x ODM Solder	1/4''	3.976	0.276	0.945	0.551	0.551	1.063
SGI / SGN 12s	ODF x ODM Solder	5/16''	5.748	0.394	1.102	0.63	0.748	1.063

Technical Data of SG series Refrigeration Sight Glass:

Danfoss Type SG SGN SGI Sight Glass 1/4'' 3/8'' 1/2'' 5/8'' 7/8'' ODF x ODF 2
