Name: FDF series FDF4A Refrigeration Solenoid Valve For Ice Maker AC220V
Brand: Ningbo Brando Hardware Co., Ltd
SKU: FDF4A
Price: 65.00 USD
Availability: InStock

Thuis Producten De Klep van de koelingssolenoïde

FDF series FDF4A Refrigeration Solenoid Valve For Ice Maker AC220V

Productdetails:

Plaats van herkomst:	China
Merknaam:	BRANDO
Certificering:	None
Modelnummer:	FDF4A

Betalen & Verzenden Algemene voorwaarden:

Min. bestelaantal:	5 stuks
Prijs:	Onderhandelbaar
Verpakking Details:	Binnendoos, karton, pallet
Levertijd:	Onderhandeling
Betalingscondities:	T/T,Western Union,MoneyGram
Levering vermogen:	100.000 stuks per maand

Contact

Gedetailleerde productomschrijving

Productnaam:	De Klep van de koelingssolenoïde	Buis OD (mm):	6.35
Opening van de opening:	4,0 mm	Draadtype:	Vliegende Lood
Normale positie:	NC (normaal gesloten)	Handeling:	Direct acteren
Spanning:	24 V DC, 24 V AC, 110 V AC, 220 V AC	Sollicitatie:	Airconditioning, warmtepomp, ijsmachine, vriezer, koeler, enz.
Maximale bedrijfsdruk:	4.5 MPa
Markeren:	FDF4A refrigeration solenoid valve , FDF series refrigeration solenoid valve air conditioning , Sanhua FDF4A Solenoid Valve

FDF series FDF4A Refrigeration Solenoid Valve For Ice Maker AC220V

FDF series solenoid valves are direct operated or pilot operated solenoid valves, mainly used in refrigerant control of various devices such as refrigerating and freezing systems, air conditioners and heat pumps.

* Applicable for all common HCFC, HFC refrigerants such as: R22, R134a, R404A, R407C, R410A, R507, R407A/F, R448A/R449A, R452A, R450A/R513A)
* Applicable medium temperature: -30ºC to +120ºC;
* Applicable ambient temperature: -30ºC to +50ºC;
* Relative humidity: below 95%
* Installation position:
1. Liquid, suction and discharge line
2. Coil upwards, coil axis ± 15º tolerance versus vertical axis
3. Flow direction corresponds to the arrow

Technical Data of FDF NC Series Solenoid Valve:

Model	FDF2A94	FDF2.5A06	FDF3A08	FDF4A10	FDF6A58	FDF8A21	FDF11A05	FDF13A07
Actuation	Direct	Pilot
Kv(m³/h)	0.08	0.2	0.26	0.3	0.56	1.29	2.4	3.44
Max. OPD (MPa)	3.4	3.4	3.4	3.4	3.4	2.8	2.8	2.8
Min. OPD (MPa)	0	0.01	0.01	0.01	0.01	0.01	0.02	0.02
MOP (MPa)	4.5
Normal Position	NC
Tube OD (inch)	1/4''	1/4''	5/16''	1/4''	5/16''	3/8''	1/2''	5/8''
Tube OD (mm)	6.35	6.34	7.94	6.35	7.94	9.52	12.7	15.88

Main Dimension of FDF NC Series Solenoid Valve:

FDF series FDF4A Refrigeration Solenoid Valve For Ice Maker AC220V 0

Model	Measurement (mm)
Model	L	L1	L2
FDF 2A 94	67	32	34
FDF 2.5A 08	85	38	38
FDF 3A 08	81	35	36
FDF 4A 10	81	35	38
FDF 6A 58	81	35	36
FDF 8A 21	114	62	62
FDF 11A 16	113	61	61
FDF 13A 12	114	62	62
