1/8'' 2 Way Normally Open Food Grade Safe PA66 Plastic Solenoid Valve AC110V KF04

1/8'' 2 Way Normally Open Food Grade Safe PA66 Plastic Solenoid Valve AC110V KF04

  • 1/8'' 2 Way Normally Open Food Grade Safe PA66 Plastic Solenoid Valve AC110V KF04
  • 1/8'' 2 Way Normally Open Food Grade Safe PA66 Plastic Solenoid Valve AC110V KF04
  • 1/8'' 2 Way Normally Open Food Grade Safe PA66 Plastic Solenoid Valve AC110V KF04
  • 1/8'' 2 Way Normally Open Food Grade Safe PA66 Plastic Solenoid Valve AC110V KF04
1/8'' 2 Way Normally Open Food Grade Safe PA66 Plastic Solenoid Valve AC110V KF04
Productdetails:
Plaats van herkomst: China
Merknaam: BRANDO
Certificering: None
Modelnummer: KF04
Betalen & Verzenden Algemene voorwaarden:
Min. bestelaantal: 500 stuks
Prijs: Onderhandelbaar
Verpakking Details: Binnendoos, karton, pallet
Levertijd: Onderhandeling
Betalingscondities: T/T,Western Union,MoneyGram
Levering vermogen: 100.000 stuks per maand
Contact
Gedetailleerde productomschrijving
Productnaam: Magneetventiel Poortgrootte: Inlaat: 1/8''; Uitlaat: 5,3 mm buitendiameter
Opening van de opening: 1,2 mm Afdichtingsmateriaal: FKM (voedselrang)
Werkdrukbereik: 0 tot 20 bar Lichaamsmateriaal: PA66
Spanning: AC110V Stroom: 8W
Sollicitatie: Koffiezetapparaat, Drankmachine, enz. Functie: 2 normaal Open manier
Markeren:

2 Way NO Solenoid Valve For Coffee Espresso Maker

,

Food Grade Safe PA66 Plastic Water Solenoid Valve

,

PA66 Plastic Water Solenoid Valve 1/8''

1/8'' 2 Way Normally Open Food Grade Safe PA66 Plastic Solenoid Valve AC110V KF04


Product Features:

1. Working Medium: Air, Water, etc
2. Working Pressure Range: 0 to 20 bar
3. Medium Temperature Range: -30 to +150ºC
4. Port Size: Inlet: 1/8''; Outlet:5.3mm OD
5. Orifice Size: 1.2mm
6. Body Material: PA66
7. Seal Material: FKM (food grade)
8. Function: 2 Way Normally Open
9. Operation: Direct Acting
10. Voltage: AC110V
11. Application: Coffee Maker, Beverage Machine, etc


Technical Data:

1/8'' 2 Way Normally Open Food Grade Safe PA66 Plastic Solenoid Valve AC110V KF04 0

Model
Port Size
Orifice
(mm)
Working Pressure
(bar)
Body Material
Seal Material
Function
Voltage
KF04
Inlet: 1/8''; Outlet:5.3mm OD
1.2
20
PA66
FKM
food grade
2 Way Normally Open
AC110V


Production Show:

1/8'' 2 Way Normally Open Food Grade Safe PA66 Plastic Solenoid Valve AC110V KF04 1



Similar Products:

1/8'' 2 Way Normally Open Food Grade Safe PA66 Plastic Solenoid Valve AC110V KF04 2 1/8'' 2 Way Normally Open Food Grade Safe PA66 Plastic Solenoid Valve AC110V KF04 3 1/8'' 2 Way Normally Open Food Grade Safe PA66 Plastic Solenoid Valve AC110V KF04 4 1/8'' 2 Way Normally Open Food Grade Safe PA66 Plastic Solenoid Valve AC110V KF04 5


Focus on your demands, Offer you best solution:


√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing


Welcome to your any question and inquiry!
