RCA5D0 RCA5D1 RCA5D2 Goyen Type Remote Pilot Valve 1/4'' 12V 24V 110V 220V

RCA5D0 RCA5D1 RCA5D2 Goyen Type Remote Pilot Valve 1/4'' 12V 24V 110V 220V

  • RCA5D0 RCA5D1 RCA5D2 Goyen Type Remote Pilot Valve 1/4'' 12V 24V 110V 220V
  • RCA5D0 RCA5D1 RCA5D2 Goyen Type Remote Pilot Valve 1/4'' 12V 24V 110V 220V
  • RCA5D0 RCA5D1 RCA5D2 Goyen Type Remote Pilot Valve 1/4'' 12V 24V 110V 220V
  • RCA5D0 RCA5D1 RCA5D2 Goyen Type Remote Pilot Valve 1/4'' 12V 24V 110V 220V
  • RCA5D0 RCA5D1 RCA5D2 Goyen Type Remote Pilot Valve 1/4'' 12V 24V 110V 220V
  • RCA5D0 RCA5D1 RCA5D2 Goyen Type Remote Pilot Valve 1/4'' 12V 24V 110V 220V
RCA5D0 RCA5D1 RCA5D2 Goyen Type Remote Pilot Valve 1/4'' 12V 24V 110V 220V
Productdetails:
Plaats van herkomst: China
Merknaam: Brando
Certificering: CE, ISO
Modelnummer: RCA5D
Betalen & Verzenden Algemene voorwaarden:
Min. bestelaantal: 100 stuks
Prijs: Onderhandelbaar
Verpakking Details: Binnenkast, doos, pallet
Levertijd: 4 tot 7 werkdagen
Betalingscondities: T/T, Paypal, Western Union, L/C
Levering vermogen: 100000 stuks per maand
Contact
Gedetailleerde productomschrijving
Poortgrootte: 1/4'' Draadtype: NPT, BSPP
Klepstructuur: Rechte hoek, poort met schroefdraad Afdichtingsmateriaal: NBR, FKM
Werkdrukbereik: 0 tot 0,85 MPa Spoelspanning: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Markeren:

RCA5D0 Remote Pilot Valve

,

RCA5D2 Remote Pilot Valve

,

Goyen RCA5D2 Solenoid Valve

RCA5D0 RCA5D1 RCA5D2 Goyen Type Remote Pilot Valve 1/4'' 12V 24V 110V 220V



Solenoid pilot valves are specifically designed for the reverse pulse jet filter cleaning of dust collectors and baghouses. These include all variations of bag filters, cartridge filters, envelope filters, ceramic filters and sintered metal fiber filters. Their tough and reliable construction makes them perfectly suited for both noxious and environmental dust collection applications in a wide range of industries, including:



1. Cement dust collection
2. Mining dust collection
3. Silo/bulk materials handling dust collection
4. Industrial dust collection
5. Power industry: protection of boilers and gas turbine intake filter systems



Ordering Code of RCA5D Solenoid Pilot Valve:

Model No
Port Size
Coil Connector
Voltage
Working Pressure
Seal Material
RCA5D1-531
(Old Model: RCA5D2-T/1009B)
NPT1/4''
Screw Terminal
220VAC
0 to 125 PSI
NBR (Standard)
FKM (Optional)
RCA5D1-530
(Old Model: RCA5D2-T/1151B)
110VAC
RCA5D1-535
24VAC
RCA5D1-537
48VDC
RCA5D1-532
(Old Model: RCA5D2-T/1054B)
24VDC
RCA5D1-534
12VDC


Main Dimension of RCA5D Solenoid Pilot Valve:

RCA5D0 RCA5D1 RCA5D2 Goyen Type Remote Pilot Valve 1/4'' 12V 24V 110V 220V 0

More Goyen Type Pulse Valves for you to choose:

RCA5D0 RCA5D1 RCA5D2 Goyen Type Remote Pilot Valve 1/4'' 12V 24V 110V 220V 1 RCA5D0 RCA5D1 RCA5D2 Goyen Type Remote Pilot Valve 1/4'' 12V 24V 110V 220V 2 RCA5D0 RCA5D1 RCA5D2 Goyen Type Remote Pilot Valve 1/4'' 12V 24V 110V 220V 3 RCA5D0 RCA5D1 RCA5D2 Goyen Type Remote Pilot Valve 1/4'' 12V 24V 110V 220V 4
T Series DD Series FS Series MM Series
RCA5D0 RCA5D1 RCA5D2 Goyen Type Remote Pilot Valve 1/4'' 12V 24V 110V 220V 5 RCA5D0 RCA5D1 RCA5D2 Goyen Type Remote Pilot Valve 1/4'' 12V 24V 110V 220V 6 RCA5D0 RCA5D1 RCA5D2 Goyen Type Remote Pilot Valve 1/4'' 12V 24V 110V 220V 7 RCA5D0 RCA5D1 RCA5D2 Goyen Type Remote Pilot Valve 1/4'' 12V 24V 110V 220V 8
RCA Series Solenoid Coil Solenoid Armature Diaphragm


Focus on your demands, Offer you best solution:



√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing



Welcome to your any question and inquiry!
