Name: 1/4'' PTFE Solenoid Valve For Acid Alkali Corrosion Resistance Isolation
Brand: Ningbo Brando Hardware Co., Ltd
SKU: 6.16BAP030B02
Price: 25.00 USD
Availability: InStock

Thuis Producten Plastic Solenoïdeklep

1/4'' PTFE Solenoid Valve For Acid Alkali Corrosion Resistance Isolation

Productdetails:

Plaats van herkomst:	NINGBO, CHINA
Merknaam:	BRANDO
Certificering:	None
Modelnummer:	6.16BAP030B02

Betalen & Verzenden Algemene voorwaarden:

Min. bestelaantal:	200
Prijs:	Onderhandelbaar
Verpakking Details:	binnendozen, dozen, pallets
Levertijd:	Onderhandeling
Betalingscondities:	T/T,Paypal,Western Union
Levering vermogen:	100000 stuks per maand

Contact

Gedetailleerde productomschrijving

Functie:	2 Gesloten manier, normaal	Poortgrootte:	1/4''
Opening van de opening:	3 mm	Materiaal kleplichaam:	PTFE
Afdichtingsmateriaal:	PTFE	Werkdrukbereik:	0 tot 0,15 MPa
Spanningen:	12VDC, 24VDC, 110VAC, 220VAC
Markeren:	1/4'' Anti-corrosive PTFE Solenoid Valve , Anti-corrosion PTFE Solenoid Valve , Anti-corrosion Solenoid Valve 1/4''

1/4'' PTFE Solenoid Valve For Acid Alkali Corrosion Resistance Isolation

Product Features:

Our isolation solenoid valves offer instrument designers a completely inert, non-metallic fluid path. The valves use a flexible diaphragm to isolate the solenoid actuation mechanism from the fluid path. Isolation Valves offer low internal volumes, precise flow control and excellent ease of installation making them particularly suitable for use in highly aggressive and / or high purity fluid applications such as analytical chemistry and clinical diagnostics. The highly inert fluid path is especially useful in liquid chromatography, genomics and protein synthesis applications. The high flow factor makes these valves well suited to environmental and water analysis applications.

Technical Data of Isolation Solenoid Valve:

Model No.	Port size	Orifice (mm)	Cv	Mini Pressure	Max Pressure		Seal Material
					AC(6VA)	DC(10W)
6.16BAP030BM8	M8x1	3.0	0.1	0.0MPa	0.3MPa	0.3MPa	PTFE
6.16BAP030B01	1/8''	3.0	0.1	0.0MPa	0.3MPa	0.3MPa
6.16BAP030B02	1/4''	3.0	0.1	0.0MPa	0.15MPa	0.15MPa
					AC(24VA)	DC(13W)
6.16BAP060B02	1/4''	6.0	0.28	0.0MPa	0.15MPa	0.15MPa
6.16BAP060B03	3/8''	6.0	0.28	0.0MPa	0.15MPa	0.15MPa
6.16BAP060B04	1/2''	6.0	0.28	0.0MPa	0.15MPa	0.15MPa
6.16BAP060B06	3/4''	6.0	0.28	0.0MPa	0.15MPa	0.15MPa
