Name: 1/8'' 1/4'' 2 Way Normally Open Stainless Steel Solenoid Valve 30bar
Brand: Ningbo Brando Hardware Co., Ltd
SKU: 19.13BAS
Price: 26.00 USD
Availability: InStock

Thuis Producten De Klep van de roestvrij staalsolenoïde

1/8'' 1/4'' 2 Way Normally Open Stainless Steel Solenoid Valve 30bar

Productdetails:

Plaats van herkomst:	NINGBO, CHINA
Merknaam:	BRANDO
Certificering:	CE, ISO
Modelnummer:	19.13BAS

Betalen & Verzenden Algemene voorwaarden:

Min. bestelaantal:	50 STUKS
Prijs:	Onderhandelbaar
Verpakking Details:	Doos, doos, pallet
Levertijd:	7 werkdagen
Betalingscondities:	T/T, PayPal, Western Union
Levering vermogen:	200000 pcs per maand

Contact

Gedetailleerde productomschrijving

Productnaam:	Magneetklep	Poortgrootte:	1/8 '', 1/4 ''
Opening van de opening:	1.2mm, 1.5mm, 2mm, 2.5mm, 2.8mm	Lichaamsmateriaal:	Roestvrij staal 304
Afdichtingsmateriaal:	NBR (standaard), EPDM, FKM (facultatief)	Werkende media:	Lucht, water, stoom, gas, vloeistof, lichte olie, enz.
Mediatemperatuur:	NBR (-10 tot +80°C), EPDM (-30 tot +120°C), FKM (-30 tot +150°C)	Werkdruk:	0 tot 30 bar
Operatie:	Direct werkend plunjer	Functie:	2 normaal Open manier
Spanning:	12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Markeren:	Normally Open Stainless Steel Solenoid Valve , 1/8'' Stainless Steel Solenoid Valve , 2 Way NO Solenoid Valve

1/8'' 1/4'' 2 Way Normally Open Stainless Steel Solenoid Valve 30bar

This is a small and compact solenoid valve, 1/8'' or 1/4'' port, 1.2 to 2.8mm orifice, 0 to 30 bar, plunger direct acting, 2 way normally open, stainless steel 304 body, NBR standard seal, can be customized as EPDM or FKM seal to suit different working mediums, various voltages for your choice, such as 12VDC, 24VDC, 24VAC, 110VAC and 220VAC, etc. It is used for a wide arrange of industrial applications to control fluids.

Technical Data:

Model No	Port Size (inch)	Orifice Size (mm)	Cv	Working Pressure (bar)		Body	Seal	Voltage
Model No	Port Size (inch)	Orifice Size (mm)	Cv	DC	AC	Body	Seal	Voltage
2 Way Normally Closed, Direct Acting
19.13BAX012BXX	1/8'' 1/4''	1.2	0.09	0 to 30	0 to 30	Brass SS304	NBR EPDM FKM	12VDC 24VDC 24VAC 110VAC 220VAC
19.13BAX015BXX		1.5	0.11	0 to 30	0 to 30
19.13BAX020BXX		2.0	0.15	0 to 20	0 to 15
19.13BAX025BXX		2.5	0.18	0 to 14	0 to 10
19.13BAX028BXX		2.8	0.25	0 to 10	0 to 8
2 Way Normally Open, Direct Acting
19.13BBX012KXX	1/8'' 1/4''	1.2	0.09	0 to 10	0 to 10	Brass SS304	NBR EPDM FKM	12VDC 24VDC 24VAC 110VAC 220VAC
19.13BBX015KXX		1.5	0.11	0 to 9	0 to 9
19.13BBX020KXX		2.0	0.15	0 to 6	0 to 6
19.13BBX025KXX		2.5	0.18	0 to 4	0 to 4
19.13BBX028KXX		2.8	0.25	0 to 3	0 to 3
