Name: 2W150-15 1/2'' Airtac Type Brass Solenoid Valve for Water Air Gas Liquid
Brand: Ningbo Brando Hardware Co., Ltd
SKU: 2W150-15
Price: 51.00 USD
Availability: InStock

Thuis Producten De Klep van de messingssolenoïde

2W150-15 1/2'' Airtac Type Brass Solenoid Valve for Water Air Gas Liquid

Productdetails:

Plaats van herkomst:	Ningbo, China
Merknaam:	BRANDO
Certificering:	None
Modelnummer:	2W150-15

Betalen & Verzenden Algemene voorwaarden:

Min. bestelaantal:	100 STUKS
Prijs:	Onderhandelbaar
Verpakking Details:	Doos, karton, pallet
Levertijd:	Onderhandelingen
Betalingscondities:	T/T, PayPal, Western Union
Levering vermogen:	100000 stuks per maand

Contact

Gedetailleerde productomschrijving

Naam van het product:	Solenoïde klep	Portgrootte:	1/2“
grootte van de opening:	15 mm	Materiaal van het lichaam:	metalen
Zeehondenmateriaal:	NBR (standaard), EPDM, FKM (facultatief)	Werkmedium:	Water, Lucht, Gas, Vloeistof, enz.
Functie:	2/2 normaal Gesloten Manier	Actie:	Pilot uitgevoerd
Werkdruk:	0,5 tot 10 Bar	Spanning:	12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Markeren:	Airtac Solenoid Valve 2W150-15 , Brass Solenoid Water Valve , Solenoid Brass Valve 1/2''

2W150-15 Airtac Type Brass Solenoid Valve

Product Features:

1. Working Medium: Water, Air, Gas, Liquid, etc

2. Max Working Pressure: 10 bar

3. Medium Temperature: NBR (-5 to +80ºC), EPDM (-5 to +120ºC), FKM (-10 to +150ºC)

4. Port Size: 1/8'', 1/4'', 3/8'', 1/2'', 3/4'', 1''

5. Orifice Size: 3mm, 5mm, 15mm, 20mm, 25mm

6. Body Material: Brass

7. Seal Material: NBR (Standard), EPDM, FKM

8. Operation: Direct Acting (DN3 to DN5), Pilot Operated (DN15 to DN25)

9. Function: 2 Way Normally Closed

10. Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz)

Technical Data:

Model No	2W030-06	2W030-08	2W050-10	2W050-15	2W150-10	2W150-15	2W200-20	2W250-25
Port Size	1/8''	1/4''	3/8''	1/2''	3/8''	1/2''	3/4''	1''
Orifice Size	3mm	3mm	5mm	5mm	15mm	15mm	20mm	25mm
CV	0.33	0.33	0.83	0.83	5.5	5.5	9.5	12.5
Body Material	Brass
Seal Material	NBR (Standard), EPDM, FKM
Working Medium	Water, Air, Gas, Liquid, etc
Working Temperature	NBR: -5 to +80℃ EPDM: -5 to +120℃ FKM: -10 to +150℃
Working Pressure	0 to 10 bar				0.5 to 10 bar
Operation	Direct Acting				Pilot Operated
Function	2 Way Normally Closed
Supply Voltage	12VDC, 24VDC, 24VAC, 110VAC, 220VAC

Main Dimension:

Model No	Port	A	B	C	D	L
2W030-06	1/8''	60	25	70	41	16
2W030-08	1/4''	60	25	70	41	16
2W050-10	3/8''	72	31	85	52	23
2W050-15	1/2''	72	31	85	52	23
2W150-10	3/8''	92	46	105	70	/
2W150-15	1/2''	92	46	105	70	/
2W200-20	3/4''	96	53	113	82	/
2W250-25	1''	102	59	122	92	/
