| Plaats van herkomst: | Ningbo, China |
| Merknaam: | BRANDO |
| Certificering: | CE, ISO |
| Modelnummer: | BC-12-2 |
| Min. bestelaantal: | 1pc |
|---|---|
| Prijs: | Onderhandelbaar |
| Verpakking Details: | Doos, karton, pallet |
| Levertijd: | 4 tot 7 werkdagen |
| Betalingscondities: | T/T, PayPal, Western Union |
| Levering vermogen: | 5000 stuks per maand |
| Naam van het product: | Pulsregelaar | Kanaalnummer: | 12 |
|---|---|---|---|
| Inlaatspanning: | 220Vac | Uitgangsspanning: | 220Vac |
| Breedte van de puls: | 0.01 tot 99,99s | Pulsinterval: | 1 tot 9999 |
| Cyclusinterval: | 1 tot 9999 | Toepassing: | Stofcollector |
| Markeren: | 12 Lines Pulse Controller,Pulse Valve Timer,Dust Collector Timer Controller |
||
220VAC Input 220VAC Output 12 Lines Pulse Valve Timer Controller For Dust Collector
Pulse Controller is a pulse jet bag filter control device in cleaning system, its output signal to control Pulse Jet Valve, blow compressed air bag sequential cleaning, so dust remains in the design within a predetermined range, in order to protect the processing power and dust collecting effect.
1. Channel Number: the number of pulse valves in the equipment (off-line mode is the number of pulse valves in a single chamber);
2. Pulse Width: the working time of the pulse valve (blowing time);
3. Pulse Interval: the interval between 2 pulse valves;
4. Cycle Interval: the interval between the end of one cycle and the start of the next cycle;
Technical Data:
| Model No | BC-08 | BC-10 | BC-12 | BC-16 | BC-20 | BC-24 | BC-30 | BC-36 | BC-52 | BC-64 |
| Channel No | 8 | 10 | 12 | 16 | 20 | 24 | 30 | 36 | 52 | 64 |
| Input Voltage | 24VDC, 110VAC, 220VAC, other can be customized | |||||||||
| Output Voltage | 24VDC, 24VAC, 110VAC, 220VAC, other can be customized | |||||||||
| Pulse Width | 0.1 to 999.9 Seconds | |||||||||
| Pulse Interval | 1 to 9999 Seconds | |||||||||
| Cycle Interval | 1 to 9999 Seconds | |||||||||
| Working Environment | 1. -25°C to +55°C 2. The relative humidity of the air does not exceed 85% 3. No serious corrosion gas and conductive dust 4. No violent vibration or shock |
|||||||||
Detailed Images:
Controller Setting:
Controller Wiring:
Our Production:
