The multi-purpose 3/2 way direct acting solenoid valves are mainly suitable in the neutral gaseous and liquid fluid pipeline automatically control. It is suitable the medium of gas, water, oil, vacuum, steam. Can be operated with zero pressure difference & circulation direction is random.
Product Features:
1. Working Medium: Air, Water, Steam, Oil, Gas, Vaccum, etc.
2. Working Pressure Range: 0 to 1 MPa (See the parameter table below for details)
3. Medium Temperature Range: NBR (-10 to +80℃), EPDM (-30 to +120℃), FKM (-30 to +150℃)
4. Port Size: 1/8'', 1/4''
5. Orifice Size: 1.5mm, 2.0mm, 2.5mm, 3.0mm, 4.0mm
6. Body Material: Brass, Stainless Steel
7. Seal Material: NBR, EPDM, FKM
8. Function: 3 Way Normally Closed, 3 Way Normally Open, Universal
9. Operation: Direct Acting
10. Voltage Option: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz)
Main Dimension of VX Series Solenoid Valve:
Technical Data of VX Series Solenoid Valve:
Model
Function
Orifice Size
(mm)
Port Size
(inch)
CV
Working Pressure (bar)
Medium Temperature
AC
DC
VX31
3 Way, Normally Closed
1.5
1/8'', 1/4''
0.07
13
11
NBR: -5 to +85℃,
EPDM: -5 to +150℃,
FKM: -10 to +150℃
2.0
0.14
11
9
2.5
0.21
9
7
3.0
0.25
6
4
4.0
0.35
3.5
2
VX32
3 Way, Normally Open
1.5
0.07
13
11
2.0
0.14
11
9
2.5
0.21
9
7
3.0
0.25
6
4
4.0
0.35
3.5
2
VX33
3 Way, Universal Operation
1.5
0.07
13
11
2.0
0.14
11
9
2.5
0.21
9
7
3.0
0.25
6
4
4.0
0.35
3.5
2
Working flow direction of VX Series Solenoid Valve:
